ALSO FITS Iveco TRUCKS 7.8 9.5 10.3 12.9 Diesel
YEARS 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023
Unit information
Voltage    24
Family type    10PA17C
Physical information
F    Dist. between holes 1    70.00
F    Dist. between holes 2    70.00
G1    Dist. between mount. bracket/hole    115.00
G2    Dist. between mount. bracket/hole 2    126.00
G3    Dist. between mount. bracket/hole 3    128.00
G4    Dist. between mount. bracket/hole 4    128.00
L    Position    57
M    Position 2    2
C    Length mm    227.00
Rotation    CW
L    Inlet    14.50
M    Outlet    11.80
Pulley information
B1    Pulley Dist. B1    38.00
B2    Pulley Dist. B2    27.00
Pulley Grooves    4
Pulley type    SP
A    Pulley OD mm    110.00
Misc. information
Oil type    PAG 46
Oil capacity    200 ml
Refrigerant    R134a
O-ring    w/o
This compressor fits many engines, if your engine or part number is not listed below please message me for an instant response.
Part number Cross Reference
This compressor replaces any compressor with following part numbers.
If your part number is not listed below please message me for an instant response.
4371006450    Denso
4422005750    Denso
4471705430    Denso
447170-5430    Denso
4471708600    Denso
4471708610    Denso
4472005750    Denso
447200-5750    Denso
4473008120    Denso
4471705430    Denso
4471705431    Denso
4472005750    Denso
4473008120    Denso
DCP12009    Denso
ACE12005    Edge
500391499    Fiat
F032240848    HC-Cargo
0000099488569    Iveco
500341617    Iveco
500391499    Iveco
504385146    Iveco
99488569    Iveco
500391499    Iveco
504385146    Iveco
99488569    Iveco
99488569AS    Iveco
70817367    Mahle
ACP793000P    Mahle
ACP793000S    Mahle
090505028    PSH
DAC8634855    Remy (delco)
1200    Sanden
SE10B171200    Sanden
